PS100 Long Scale 100mm in 0.1mm divisions
PS100 Long Scale 100mm in 0.1mm divisions
Pattern
PS100
Description
Long Scale 100mm/0.1mm
Key features
Long Glass Scale with 100mm scale subdivided into 1000 divisions of 0.1mm (100µm)
Ideal for Profile Projectors using lower magnifications. For higher magnification, CMM's and Vision Systems the High Definition products, such as PS100HS MKII or PS100XO, will be more suitable.
Glass Type and Thickness
Green Float 6mm thick
Dimensions
140mm x 30mm
Line Thickness
0.03mm
Overall Accuracy
Within 0.015mm
