NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1

NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1

Pattern

NE57

Description

Miller Squares Ratio 9:1

Key features

Eyepiece Reticle with Miller Squares pattern, 7x7 mm large square. The ratio of large to small square is 9:1

Line Thickness

0.015mm +/-0.003mm

Glass Type and Thickness

Soda Lime 1.5mm thick

Diameter Tolerance

+0/-0.1mm

Overall Tolerance

+/-0.010mm

Orientation

Correct reading through glass

Documentation

SDS

Technical Notes

🚚 Estimated Delivery: 5 - 6 weeks from payment confirmation

View full details
Variant Variant total Quantity Price Variant total
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 16mm diameter (Unit: each)01B16232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 16mm diameter (Unit: each)01B16232
1.391,54 lei/ea		 0,00 lei
1.391,54 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 19mm diameter (Unit: each)01B19232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 19mm diameter (Unit: each)01B19232
1.391,54 lei/ea		 0,00 lei
1.391,54 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 20.4mm diameter (Unit: each)01B20.4232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 20.4mm diameter (Unit: each)01B20.4232
1.391,54 lei/ea		 0,00 lei
1.391,54 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 21mm diameter (Unit: each)01B21232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 21mm diameter (Unit: each)01B21232
1.391,54 lei/ea		 0,00 lei
1.391,54 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 23mm diameter (Unit: each)01B23232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 23mm diameter (Unit: each)01B23232
1.391,54 lei/ea		 0,00 lei
1.391,54 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 24mm diameter (Unit: each)01B24232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 24mm diameter (Unit: each)01B24232
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 24.5mm diameter (Unit: each)01B24.5232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 24.5mm diameter (Unit: each)01B24.5232
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 25mm diameter (Unit: each)01B25232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 25mm diameter (Unit: each)01B25232
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 26mm diameter (Unit: each)01B26232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 26mm diameter (Unit: each)01B26232
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 27mm diameter (Unit: each)01B27232
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, 27mm diameter (Unit: each)01B27232
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, other diameter (Unit: each)NE57OTHER
NE57 Miller Square, 7 x 7 mm large square with smaller square, ratio 9:1, other diameter (Unit: each)NE57OTHER
2.277,28 lei/ea		 0,00 lei
2.277,28 lei/ea 0,00 lei
