NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters

NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters

Pattern

NE43

Description

Concentric Circles 0.5mm-5mm

Key features

Eyepiece Reticle with 10 Concentric Circles ranging in size from 0.5mm to 5mm diameter in 0.5mm steps. 5th circle has dashed lines

Line Thickness

0.008mm +/-0.002mm

Glass Type and Thickness

Soda Lime 1.5mm thick

Overall Tolerance

+/-0.005mm

Diameter Tolerance

+0/-0.1mm

Cross Line Length

12.5mm approx.

Orientation

Correct reading through glass

Documentation

SDS

Technical Notes

🚚 Estimated Delivery: 5 - 6 weeks from payment confirmation

View full details
Variant Variant total Quantity Price Variant total
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 16mm diameter (Unit: each)01B16225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 16mm diameter (Unit: each)01B16225
1.392,07 lei/ea		 0,00 lei
1.392,07 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 19mm diameter (Unit: each)01B19225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 19mm diameter (Unit: each)01B19225
1.392,07 lei/ea		 0,00 lei
1.392,07 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 20.4mm diameter (Unit: each)01B20.4225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 20.4mm diameter (Unit: each)01B20.4225
1.392,07 lei/ea		 0,00 lei
1.392,07 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 21mm diameter (Unit: each)01B21225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 21mm diameter (Unit: each)01B21225
1.392,07 lei/ea		 0,00 lei
1.392,07 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 23mm diameter (Unit: each)01B23225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 23mm diameter (Unit: each)01B23225
1.392,07 lei/ea		 0,00 lei
1.392,07 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 24mm diameter (Unit: each)01B24225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 24mm diameter (Unit: each)01B24225
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 24.5mm diameter (Unit: each)01B24.5225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 24.5mm diameter (Unit: each)01B24.5225
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 25mm diameter (Unit: each)01B25225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 25mm diameter (Unit: each)01B25225
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 26mm diameter (Unit: each)01B26225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 26mm diameter (Unit: each)01B26225
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 27mm diameter (Unit: each)01B27225
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, 27mm diameter (Unit: each)01B27225
1.776,63 lei/ea		 0,00 lei
1.776,63 lei/ea 0,00 lei
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, other diameter (Unit: each)NE43OTHER
NE43 Concentric Circles, 10 circles, 0.5mm-5mm diameters, other diameter (Unit: each)NE43OTHER
2.783,93 lei/ea		 0,00 lei
2.783,93 lei/ea 0,00 lei
